LEMKEN·Tillage
Disc harrow LEMKEN Heliodor 9
Compact disc harrow, 2 to 7 m wide, for shallow stubble cultivation and seedbed preparation.
Main advantages
- 13 sizes — width matched to the tractor
- 50 to 175 hp requirement — small to large tractors
- Low weight — high working speed
- Combines with seeding — several jobs in one pass
Size
Heliodor 9/200
- Working width
- 2 m
- Weight
- 570 kg
- Required tractor power
- 50 HP
- Number of discs
- 16
- Disc diameter
- 510 mm
Overview
About this product
The Heliodor 9 is a compact disc harrow with working widths from 2 to 7 m for shallow stubble cultivation on light and medium soils or for seedbed preparation. Its low weight allows high working speeds with a low power requirement. It can be combined with units for sowing, catch crop sowing or slurry application.
Sizes
Heliodor 9 sizes
| Size | Working width | Weight | Required tractor power | Number of discs | Disc diameter |
|---|---|---|---|---|---|
| 2 m | 570 kg | 50 HP | 16 | 510 mm | |
| 4 m | 1084 kg | 100 HP | 32 | 510 mm | |
| 3.5 m | 968 kg | 88 HP | 28 | 510 mm | |
| 3 m | 852 kg | 75 HP | 24 | 510 mm | |
| 2.5 m | 712 kg | 63 HP | 20 | 510 mm | |
| 6 m | 2206 kg | 150 HP | 48 | 510 mm | |
| 7 m | 2482 kg | 175 HP | 56 | 510 mm | |
| 5 m | 1928 kg | 125 HP | 40 | 510 mm | |
| 4.5 m | 1859 kg | 112 HP | 36 | 510 mm | |
| 4 m | 1791 kg | 100 HP | 32 | 510 mm | |
| 5 m | 3151 kg | 150 HP | 40 | 510 mm | |
| 6 m | 3362 kg | 150 HP | 48 | 510 mm | |
| 7 m | 3582 kg | 150 HP | 56 | 510 mm |
Specifications
Key machine parameters
| Brand | LEMKEN |
|---|---|
| Equipment type | Disc harrow |
| Model | Heliodor 9 |
| Working width | 2 m |
| Condition | New |
| Weight | 570 kg |
| Required tractor power | 50 HP |
| Number of discs | 16 |
| Disc diameter | 510 mm |
